MP1653 17V, 3A, 800kHz, is a fully integrated high-frequency synchronous rectification step-down switch mode converter with internal power MOSFETs. It provides a very compact solution with 3A continuous output current and excellent load and line regulation over a wide input range. In addition, the MP1653 features synchronous mode operation for higher efficiency over the output current load range.

Product features:

Wide 4.2V to 17V Operating Input Range

70mΩ/40mΩ Low RDS(ON) Internal Power MOSFETs

200μA Low IQ

High-Efficiency Synchronous Mode Operation

Power-Save Mode at Light Load

Fast Load Transient Response

800kHz Switching Frequency

Internal Soft Start

Over-Current Protection (OCP) and Hiccup

Thermal Shutdown

Output Adjustable from 0.8V

Available in a SOT563 (1.6mm*1.6mm) Package

Application:

Security Cameras

Digital Set-Top Boxes

Flat-Panel Televisions and Monitors

General Purposes
